| 特点 | 应用 |
| 使用高Q值谐振器获得的低损耗； | 基站及直放站； |
| 使用高介电常数材料获得更小的尺寸及更轻的重量； | PCS系统； |
| 可靠地机械结构、无振动结构； | CDMA系统； |
| 优良的温度稳定性； | DCS系统； |
| 适用于表面贴装； | GSM系统； |
| 频率范围：400～6000MHz | WCDMA系统； |
| 功率范围：1~30W | TRS系统； |
| TD-SCDMA系统； | |
| MMDS系统； |
规格
| 品名 | 中心频率 | 带宽 | 插损 | 波动 | 反射 | 衰减 (dB) | 尺寸 (长 x 宽 x 高)毫米 | ||||||||
| 897F1747F8R35-75FA | 897.5 | 35 | 2 | 0.5 | 14 | 45 | @ | 1710 | ~ | 1785 | 34.5 | x | 14.5 | x | 5.5 |
| 1747.5 | 75 | 2 | 0.5 | 14 | 50 | @ | 880 | ~ | 915 | ||||||
| 900F1950F8R30-60FB | 900 | 30 | 2.5 | 0.5 | 14 | 45 | @ | 1920 | ~ | 1980 | 34.5 | x | 14.5 | x | 5.5 |
| 1950 | 60 | 2.5 | 0.5 | 14 | 45 | @ | 885 | ~ | 915 | ||||||
| 902R1747F8R25-75FA | 902.5 | 25 | 2.5 | 1 | 15 | 40 | @ | 1710 | ~ | 1785 | 34.5 | x | 14.5 | x | 5.5 |
| 40 | @ | 1805 | ~ | 1880 | |||||||||||
| 15 | @ | 935 | ~ | 960 | |||||||||||
| 1747.5 | 75 | 2 | 1 | 15 | 55 | @ | 890 | ~ | 915 | ||||||
| 55 | @ | 935 | ~ | 960 | |||||||||||
| 3 | @ | 1805 | ~ | 1880 | |||||||||||
| 920F2045F8R80-250FA | 920 | 80 | 1.7 | 1 | 10 | 45 | @ | 1920 | ~ | 2170 | 34.5 | x | 14.5 | x | 5.5 |
| 2045 | 250 | 1.7 | 1 | 10 | 55 | @ | 880 | ~ | 960 | ||||||
| 925F1795F8R70-170FA | 925 | 70 | 1.7 | 1 | 10 | 50 | @ | 1710 | ~ | 1880 | 34.5 | x | 14.5 | x | 5.5 |
| 1795 | 170 | 1.7 | 1 | 10 | 60 | @ | 890 | ~ | 960 | ||||||
| 942F1842F8R35-75FB | 942.5 | 35 | 2 | 1 | 14 | 45 | @ | 1805 | ~ | 1880 | 34.5 | x | 14.5 | x | 5.5 |
| 1842.5 | 75 | 2 | 1 | 14 | 50 | @ | 925 | ~ | 960 | ||||||
| 1268R1590D6R20-50FA | 1268 | 20 | 2.5 | 1 | 9.5 | 35 | @ | 1565 | ~ | 1615 | 21.5 | x | 12.0 | x | 4.5 |
| 1590 | 50 | 2 | 1 | 9.5 | 35 | @ | 1258 | ~ | 1278 | ||||||
| 1595F2492D6R42-20FA | 1595 | 42 | 2 | 1 | 9.5 | 30 | @ | 2482 | ~ | 2502 | 21.5 | x | 13.0 | x | 4.5 |
| 2492 | 20 | 2 | 1 | 9.5 | 30 | @ | 1574 | ~ | 1616 | ||||||
| 1732F2132D6R65SA | 1732.5 | 65 | 2.5 | 0.7 | 18 | 50 | @ | 2110 | ~ | 2165 | 21.5 | x | 12.5 | x | 4.5 |
| 20 | @ | 1595 | ~ | ||||||||||||
| 2132.5 | 65 | 2.5 | 0.7 | 18 | 50 | @ | 1700 | ~ | 1765 | ||||||
| 30 | @ | 1995 | ~ | ||||||||||||
| 1732F2132F8N45FB | 1732.5 | 45 | 1.5 | 0.5 | 18 | 50 | @ | 2110 | ~ | 2155 | 34.5 | x | 14.5 | x | 5.5 |
| 2132.5 | 45 | 1.5 | 0.5 | 18 | 50 | @ | 1710 | ~ | 1755 | ||||||
| 1732F2132H10N45FA | 1732.5 | 45 | 2.5 | 0.3 | 15 | 60 | @ | 2110 | ~ | 2155 | 52.5 | x | 14.5 | x | 6.5 |
| 2132.5 | 45 | 2.5 | 0.3 | 15 | 60 | @ | 1710 | ~ | 1755 | ||||||
| 1795R2045F8N170-250FA | 1795 | 170 | 2 | 1 | 10 | 35 | @ | 1920 | ~ | 2170 | 34.0 | x | 13.8 | x | 5.0 |
